XCMG 85 ton right hand drive truck crane QY85KA_Y

XCMG 75 ton right hand drive truck crane model QY75KA_Y
Quantity:
  • QY85KA_Y

  • XCMG

  • 85 ton

  • right hand drive

  • 12.2-47 m

  • 64 m

XCMG 85 ton Right Hand Drive truck crane
Model: QY85KA_Y

Main specifications:


Dimension Unit QY85KA_Y
Overall length mm 14650
Overall width mm 2800
Overall height mm 3880
Weight
Total weight in travel kg 48000
(without counterweight)
Front 2 axles load kg 12000/12000
Rear 2 axles load kg 12000/12000
Power of engine
Engine model  WP10.375
Engine rated power kW/(r/min)  276/2200
Engine rated torque N.m/(r/min) 1460/1600
Specifications in Travel
Max. travel speed km/h 80
Min. turning diameter m 26.6
Min. ground clearance mm 427
Approach angle ° 19
Departure angle ° 15
Max. grade ability % 37
Fuel consumption for 100km L
Main performance
Max. rated total lifting capacity t 85
Min. rated working radius m 3000
Turning radius at turntable tail m 4.33
Max. lifting torque kN.m 2303
Base boom m 12.2
Fully extended boom m 47
Fully extended boom+ jib m 64
Longitudinal outrigger span m 6.1
Lateral outrigger span m 7.3
Working speed
Boom luffing time s 55
Boom full extension time s  ≤110
Max. swing speed r/min  ≥1.9
Max. speed of main winch (single rope) (no load) m/min  ≥140
Max. speed of aux. winch (single rope) (no load) m/min ≥108

Photo of XCMG 85 ton Right Hand Drive Truck Crane QY85KA_Y:
QY85KA_Y photo

If you want more information like load chart, photos, price of XCMG 85 ton Right Hand Drive truck crane QY85KA_Y, please contact us or send inquiry.
